Handling

Handling glass should always be done in a safe and efficient manner. Our partner, Elephant, from Italy, has been in the industrial lifting and handling sector for more than 35 years and have a huge range of products. Together, we can help with very specific requirements as well as standard and general lifting equipment such as vacuum lifters. Elephant and Flat Glass Solutions guarantee high standards, quality and maximum functionality.

View Brochure

Technical Features

Structural Integrity

Easy to Use

View Video

Powered by Compressed Air

For lifting, rotating and moving glass, we can supply vacuum lifters with between two and sixteen suction pads and with lifting capacities from 200 to 1200kg. Vacuum lifters for glass can be used internally (in factories or workshops) and externally (for installing glass and facades to buildings). You can choose and configure vacuum lifters with manual or automatic movements and with differing types of power supply.

View Specs

Powered by Electricity

Whatever your requirement, all of our glass handling devices are completely functional and come with many useful features to make the rotating, lifting and laying of glass simple and safe for operators.

View Specs

Insulated Double Glazing

Our twin-faced vacuum lifters can be installed near the offload of IG Lines and used for handling double-glazed units. Also available are lifting and moving clamps for large sheets of flat, bonded or laminated glass. (Please note these clamping appliances are not suitable for textured or processed surface glass.)

View Specs

Innovative Flat Glass Solutions

Require a quote? Need to speak to us?

Call: 00 44 (0)1359 256143
sales@flatglasssolutions.com

Model	Capacity (kg)	Suction Cups	Cup Diameter (mm)	Manual Rotation 0-360° 0-180° ●	Manual Tilting 0-90°	Pneumatic Rotation 0-90°	Pneumatic Tilting 0-90°
VT2R	200	2	250	●
VT4R	400	4	250	●
VT6R	600	6	300	●
VT8R	800	8	300	●
VT12R	1200	12	300	●
VT2RB	200	2	250	●	●
VT4RB	400	4	250	●	●
VT6RB	600	6	300	●	●
VT8RB	800	8	300	●	●
VT2RP	200	2	250			●
VT2BP	200	2	250				●
VT4BP	400	4	300				●
VT2RMBP	200	2	250	●			●
VT4RMBP	400	4	250	●			●
VT2RPBP	200	2	250			●	●
VT4RPBP	400	4	300			●	●

Model	Capacity (kg)	Suction Cups	Cup Diameter (mm)	Manual Rotation 0-360° 0-180° ●	Manual Tilting 0-90°	Electric Rotation 0-360°	ElectricTilting 0-90°
GP2R	200	2	250	●
GP4R	400	4	250	●
GP6R	600	6	300	●
GP8R	800	8	300	●
GP12R	1200	12	300	●
GP2RB	200	2	250	●	●
GP4RB	400	4	250	●	●
GP6RB	600	6	300	●	●
GP8RB	800	8	300	●	●
GP4RMBE	400	4	250	●			●
GP6RMBE	600	6	300	●			●
GP8RMBE	800	8	300	●			●
GP12RMBE	1200	12	300	●			●
GP2REBE	200	2	300			●	●
GP4REBE	400	4	300			●	●
GP6REBE	600	6	300			●	●
GP8REBE	800	8	300			●	●
GP12REBE	1200	12	300			●	●

Model	Capacity (kg)	Suction Cups	Cup Diameter (mm)	Movement
GP8VC	750	4+4	300	Fixed in Vertical Position
GP14VC	1200	7+7	300	Fixed in Vertical Position
